HobbyWing Platinum 260A HV V5 ESC (6-14S) - SBEC
Specification
|
Continuous/Peak current |
260A / 400A |
|
Input voltage |
6-14S LiPo battery |
|
BEC |
Switch Mode BEC; output voltage 5-12V adjustable (adjusted 0.1V); output current cont. 10A, Peak 30A |
|
Input/Output wires |
1 x black and 1x red 8AWG silicone wires / 3 x black 10AWG silicone wires |
|
Independent parameter programming interface |
Connect LCD program box or OTA module, or to power the cooling fan |
|
LED light |
Display the statuses and fault alerts |
|
Size/Weight |
89 x 50 x 34mm / 297g (With wires) |
|
Mounting holes |
M3, 39 x 98mm |
|
The scope of application |
700-800 class electric helicopter (main rotor length 700-880mm), or fixed-wing |
Users_manual_Platinum_260A_HV_SBEC_-OPTO Original: $519.99
-65%$519.99
$182.00Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Specification
|
Continuous/Peak current |
260A / 400A |
|
Input voltage |
6-14S LiPo battery |
|
BEC |
Switch Mode BEC; output voltage 5-12V adjustable (adjusted 0.1V); output current cont. 10A, Peak 30A |
|
Input/Output wires |
1 x black and 1x red 8AWG silicone wires / 3 x black 10AWG silicone wires |
|
Independent parameter programming interface |
Connect LCD program box or OTA module, or to power the cooling fan |
|
LED light |
Display the statuses and fault alerts |
|
Size/Weight |
89 x 50 x 34mm / 297g (With wires) |
|
Mounting holes |
M3, 39 x 98mm |
|
The scope of application |
700-800 class electric helicopter (main rotor length 700-880mm), or fixed-wing |
