Combove Type III 4730-520KV 1.6MM P2 36mm Shaft 6mm Brushless Motor
Specifications |
|
| Stator Diameter | 47 mm |
| Stator Thickness | 30 mm |
| No. of Stator Arms | 12 |
| Magnet Poles | 10 |
| Motor Wind | 5+5Turn Delta |
| Motor Wire | 1-Strand 1.6 mm |
| Motor Kv | 540 KV RPM / Volt |
| No-Load Current (Io/10V) | 2.15 Amps |
| Motor Resistance (Rm) | 0.015 Ohms |
| Max Continuous Current | 135 Amps |
| Max Continuous Power | 5750 Watts |
| Weight | 580 Grams |
| Outside Diameter | 58.8 mm |
| Shaft Diameter | 6 mm |
| Body Length | 62.5 mm |
| Overall Shaft Length | 112.5 mm |
| Max Lipo Cell | 12s |
| Max Peak Current | 250 A (2 seconds) |
| Max Peak Power | 12800 Watts (2 seconds) |
| Motor Timing | 5deg-8deg |
| Drive Frequency | 8kHz-32khz |
$91.00
Original: $260.00
-65%Combove Type III 4730-520KV 1.6MM P2 36mm Shaft 6mm Brushless Motor—
$260.00
$91.00Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Specifications |
|
| Stator Diameter | 47 mm |
| Stator Thickness | 30 mm |
| No. of Stator Arms | 12 |
| Magnet Poles | 10 |
| Motor Wind | 5+5Turn Delta |
| Motor Wire | 1-Strand 1.6 mm |
| Motor Kv | 540 KV RPM / Volt |
| No-Load Current (Io/10V) | 2.15 Amps |
| Motor Resistance (Rm) | 0.015 Ohms |
| Max Continuous Current | 135 Amps |
| Max Continuous Power | 5750 Watts |
| Weight | 580 Grams |
| Outside Diameter | 58.8 mm |
| Shaft Diameter | 6 mm |
| Body Length | 62.5 mm |
| Overall Shaft Length | 112.5 mm |
| Max Lipo Cell | 12s |
| Max Peak Current | 250 A (2 seconds) |
| Max Peak Power | 12800 Watts (2 seconds) |
| Motor Timing | 5deg-8deg |
| Drive Frequency | 8kHz-32khz |
